Battery Thermal Management System (BTMS)
The Modine Battery Thermal Management System is a complete thermal system solution that maintains the critical operating temperature ranges of vehicle batteries. Design solutions are available for both active and passive cooling circuits.
Features and Benefits
- Standard packaging or customized solutions available.
- Modine field proven patented master controls system.
- Specialized battery radiator and condenser specifically designed for BTMS applications.
- 2 – 10 kW cooling (typically 6 kW at 45ºC ambient).
- 6 kW passive cooling (10ºC ETD).
- 2 – 12 kW electric heating down to -20ºC coolant temperature.
- Total system weight < 80 kg.
- Operates native vehicle voltages.
- HV: 450 – 800 VDC.
- LV: 12 or 24 VDC option.
![evantage_under_trans-360x120](https://www.modine.com/wp-content/uploads/2022/05/evantage_under_trans-360x120-1.png)
As you design the future of clean technology, Modine is ready to help with proven thermal systems engineered to quickly and seamlessly integrate into your design.
